MAKING THE 1st 'BLUEPLANET' WIND TUNNEL MODEL

THE SCIENCE OF MEASUREMENT

HOME | AUTOMOTIVE | BLUEPLANET | ELECTRIC CARS | ENERGY | INSURANCE | INDEX  | SOLAR CARS





Cutting the Blueplanet's pattern in plywood



Nelson cutting plywood patterns using an electric jigsaw





To produce our first wind tunnel model of the BE3 we used the tried and tested method of producing models cheaply. Namely: cutting wooden patterns, filling the assembled patterns with foam, then shaping.



The procedure is described and illustrated on the link pages below for persons interested in model making.  Unfortunately, if you use this method, a relatively high skill level and many man hours are required to achieve a quality finish.



Steps 1.  Mark out your plywood and cut formers

Step 2.  Assemble plywood formers

Step 3. Fill formers with foam and shape

Step 4. Coat foam plug with plaster

Step 5. Sand, add detail mouldings and prime

Step 6. Paint finished model





 PLEASE NOTE: the BE3 is a registered design (3007044) and design copyright, hence may not be reproduced in model form without the express written permission of the proprietor.
